7–8

RSView32 User’s Guide
Example of short file names for wide .dbf
format
For wide .dbf file format, data log files are created in sets of two.
Example: Wide .dbf short log file name
The log file named 971028dw.dbf was created in the year 97, month
10, and day 28. The d indicates that this is the fourth file set created
that day. The w indicates that this file is in wide file format and may
contain both floating point and string tag data.
Example: Wide .dbf short log file set
If you were to look in the directory containing the data log files, you
would find two files with almost the same name.
971028dt.dbf contains the tag name data
971028dw.dbf contains the floating point data from analog and
digital tags and the string data from string tags
The ODBC storage format
Use the ODBC storage format to store your data using an ODBC data
source such as Microsoft Access or Microsoft SQL Server. The
ODBC format stores data in up to three tables, similar to narrow
format:
Tag table (optional)—stores tag names in an index so they can be
referenced using a 2- or 4-byte numeric field (rather than a 40-byte
character field) in the float and string tables
Float table—stores analog and digital tag values
