Converteon Management Software User’s Guide
41
Note
The maximum operating distances of the fiber optic ports assume
full-duplex operation. The distances will be significantly less for half-
duplex mode.
Table 2 lists the features of the line cards.
Table 2: Features of the AT-CM2 and AT-CM70S Media Converter Line Cards
Twisted Pair Port ˆ IEEE 802.3u Auto-Negotiation
ˆ Half- or full-duplex mode
ˆ Auto-MDI/MDI-X
ˆ RJ-45 connector
ˆ Back pressure in half-duplex mode
ˆ IEEE 802.3x flow control in full-duplex mode
Operating Modes ˆ Link Test
ˆ MissingLink ™
ˆ Smart MissingLink
ˆ OAM Visible
ˆ OAM Bypass
Operations, Administration, and Maintenance
(OAM)
ˆ Loopback test 1
ˆ Remote Converteon line card management
1
ˆ Remote management software downloads
1
ˆ Dying gasp 2
ˆ Variable requests
1
Other Features
ˆ Standard Ethernet frames up to 1522 bytes 3
ˆ Ingress and egress packet rate limiting
1
ˆ LEDs for unit and port status
ˆ Cyclical redundancy check
ˆ Suitable for managed and unmanaged
network environments
ˆ Management available with the AT-CV5M02
Management Card
ˆ AT-S73 Management Software
1. Requires the AT-CV5M02 Management Card.
2. Require one AT-CV5M02 Management Card in the upstream AT-CV5000 Chassis.
3. The maximum frame size of the AT-CM2K0S Line Card is 1632 bytes.
