Converteon Management Software User’s Guide
211
The columns in the window, which is for viewing purposes only, are
described in Table 25.
Web Browser
To view the MAC addresses and serial numbers of the cards from the web
browser windows:
1. Select Diagnostics from the menu bar.
2. Select the Local CM Line Card tab.
3. Select the MAC Address & Serial Number tab, shown in Figure 88 on
page 212. This window is for viewing purposes only. The columns in
the window are described in Table 25 on page 211.
Table 25. Line Card Module Information Window
Row
Description
Module
This column displays the slot numbers, the names and
the model names of the cards. For instructions on how to
assign a name to a line card, refer to “Assigning Names
to the AT-CM Line Cards” on page 181.
MAC
Address
This column displays the MAC addresses of the AT-CM
Line Cards in the chassis.
The AT-CV5M02 Management Card does not have a
MAC address. To communicate with your network, it
adopts the MAC address of its chassis. To view the MAC
address of a chassis, refer to “Displaying the Operational
Status of the Chassis” on page 148.
The AT-CV Line Cards have the MAC address
FF:FF:FF:FF:FF:FF.
Serial
Number
This column displays the serial numbers of the cards.
