Chapter 6: Configuring the Media Converter Line Cards
204
InUndersize The number of undersize frames received by a
port. An undersize frame is less than 64 octets in
length and has a valid FCS.
InFragments The number of fragments received by a port. A
fragment is less than 64 octets in length and has
an invalid FCS.
InOversize The number of oversize frames received by a
port. An oversize frame is larger than 10,240
bytes and has a valid FCS.
InJabber The number of jabber frames received by a port.
A jabber frame is larger than 10,240 bytes and
has an invalid FCS.
InRxErr The number of ingress frames that have an RxErr
signal from the PHY.
InFCSErr The number of ingress frames with CRC errors.
Frames with this error are not counted in the
InFragments, InJabber, or InRxErr counter.
OutOctetsLo The length in octets of all the frames sent by a
port. The length is given in two counters. This is
the lower 32-bits of the counter.
OutOctetsHi The length in octets of all the frames sent by a
port. The length is given in two counters. This is
the upper 32-bits of the counter.
OutUnicast The number of unicast frames sent by a port.
OutBroadcasts The number of broadcast frames sent by a port.
OutMulticasts The number of multicast frames sent by a port.
OutPause The number of pause frames sent by a port.
Deferred The number of frames that were successfully
transmitted without collisions after being delayed
one time because the medium was busy. This
counter applies only to half-duplex mode.
Collisions The number of frames that encountered a
collision and that were not counted in the Single,
Multiple, Excessive, or Late counter.
Single The number of frames that were successfully
transmitted after they encountered one collision.
This counter applies only to half-duplex mode.
Table 22. Port Statistics for the AT-CM3 Line Cards
Statistic Description
