Converteon Management Software User’s Guide
175
4. Click the Port Configuration tab to display the current settings of the
port. The example in Figure 66 is from Port B, the twisted pair port, on
a line card.
Figure 66. Port Configuration Window
5. To adjust the settings, click the Edit button to display the Port
Configuration pop-up window.
6. Adjust the parameters, as needed. The parameters are defined in
Table 21 on page 171.
7. Click the Update button. The new parameter settings take affect
immediately on the port.
8. To save your changes in the master configuration file, click the Line
Card Configuration tab, the Current Configuration tab, and the
Save Current Configuration button.
