Converteon Management Software User’s Guide

203

Displaying Port Statistics

Menus

To display the traffic statistics for the ports on the AT-CM Line Cards from
the menus:

1. From the Main Menu, select Module Status and Configuration. The

Module Status and Configuration Menu is shown in Figure 58 on page
158
.

2. Select the AT-CM Line Card whose statistics you want to view. An

example of the Module Configuration Menu is shown in Figure 63 on
page 169
.

3. Select a port. You can select only one port. The Port Management

Menu is shown in Figure 64 on page 170.

4. Select Port Configuration to display the Port Configuration Menu in

Figure 65 on page 171.

5. From the Port Configuration Menu, select Port Statistics.

6. Select Show Port Statistics. The number of statistics depends on the

line card. For the port statistics for the AT-CM3 Line Cards, refer to
Table 22. For the port statistics for the AT-CM2 and AT-CM70S Line
Cards, refer to Table 23 on page 206.

Table 22. Port Statistics for the AT-CM3 Line Cards

Statistic

Description

InGoodOctetsLo

The length in octets of all the good frames
received by a port. The length is given in two
counters. This is the lower 32-bits of the counter.

InGoodOctetsHi

The length in octets of all the good frames
received by a port. The length is given in two
counters. This is the upper 32-bits of the counter.

InBadOctets

The length in octets of all the bad frames
received by a port.

InUnicast

The number of unicast frames received by a port.

InBroadcasts

The number of broadcast frames received by a
port.

InMulticasts

The number of multicast frames received by a
port.

InPause

The number of pause frames received by a port.
