Converteon Management Software User’s Guide
259
Performing the OAM Loopback Test
For background information, refer to “OAM Loopback Tests” on page 61.
Menus
To perform the OAM loopback test from the menus:
Caution
This test is disruptive to network operations. Some network traffic
may be lost. The local and remote media converter line cards do not
forward network traffic during the test.
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration Menu. An example of the
menu is shown in Figure 58 on page 158.
2. Select the local AT-CM Line Card you want to perform the loopback
test. This displays the Module Configuration Menu for the line card. An
example of the menu is shown in Figure 63 on page 169.
3. Select Port A to display the Port Management Menu, shown in Figure
64 on page 170.
4. From the Port Management Menu, select OAM Configurations to
display the OAM Configuration Menu in Figure 105 on page 254.
5. From the OAM Configuration Menu, select OAM Loopback Test to
display the OAM Loopback Test Menu, shown in Figure 108.
Figure 108. OAM Loopback Test Menu
OAM Loopback Test
Module 11, Port = 1
Enable Remote Loopback
> Disable Remote Loopback
Start Loopback Test
> Stop Loopback Test
Show Loopback Test Statistics
Clear Loopback Test Statistics
Return to OAM Configurations ...
