Converteon Management Software User’s Guide

235

Displaying the Version Numbers of the Remote AT-CM Line Cards

These procedures are used to view the version numbers of the
management software and bootloader files on remote AT-CM Line Cards.
The management software programs of the line cards are listed here:

ˆ

The AT-CM2 and AT-CM70S Line Cards use the AT-S73 Management
Software

ˆ

The AT-CM3 Line Cards use the AT-S102 Management Software

Menus

To view the information from the menus:

1. From the Main Menu, select Diagnostics to display the Diagnostics

Menu shown in Figure 53 on page 148.

2. Select Remote CM Line Card Diagnostics.

3. From the Remote CM Line Card Diagnostics Menu, select Image

Version. An example of the Remote Line Card Module Software
Image Version window is shown in Figure 95. The information in this
window is for viewing purposes only.

Figure 95. Remote Line Card Module Software Image Version Window

Remote Line Card Module Software Image Version

Converteon

Module

App Ver.

BootLdr Ver.

1: AT-CV5M02

V4.0.1

2: Reg11

AT-CM301

V4.0.1

V4.0.0

3: Reg20

AT-CM301

V4.0.1

V4.0.0

4: Reg21

AT-CM301

V4.0.1

V4.0.0

5: Area2a

AT-CM301

V4.0.1

V4.0.0

6: Area2b

AT-CM202-v2

V4.0.1

V1.7.0

7: Reg12

AT-CM202-v2

V4.0.1

V1.7.0

8: Reg5

AT-CM202-v2

V4.0.1

V1.7.0

9: Reg17

AT-CM202

V4.0.1

V1.7.0

10: --------

AT-CV102

--

11: --------

AT-CV102

--

12: --------

AT-CV102

--

13: --------

AT-CV102

--

14: --------

AT-CV102

--

15: Unequipped

--

16: Unequipped

--

17: Unequipped

--

18: Unequipped

--

Hit any key to continue ...
