Chapter 6: Configuring the Media Converter Line Cards
208
Figure 85. Line Card Module Software Image Version Window
The columns in the window are described in Table 24.
Line Card Module Software Image Version
Converteon
Module App Ver. BootLdr Ver.
1: -------- AT-CV5M02 V4.0.1
2: Reg11 AT-CM3K0S V4.0.1 V1.7.0
3: Reg20 AT-CM301 V4.0.1 V1.7.0
4: Reg21 AT-CM301 V4.0.1 V1.7.0
5: Area2a AT-CM301 V4.0.1 V1.7.0
6: Area2b AT-CM302 V4.0.1 V1.7.0
7: a121 AT-CM202-v2 V4.0.1 V1.7.0
8: Reg12 AT-CM202-v2 V4.0.1 V1.7.0
9: -------- AT-CM202-v2 V4.0.1 V1.7.0
10: -------- AT-CM212A/1 V4.0.1 V1.7.0
11: -------- AT-CV102 --
12: -------- AT-CV102 --
13: -------- AT-CV102 --
14: -------- AT-CV102 --
15: -------- Unequipped --
16: -------- Unequipped --
17: -------- Unequipped --
18: -------- Unequipped --
Hit any key to continue ...
Table 24. Line Card Module Software Image Version Window
Row Description
Module This column displays the slot numbers, the names and
the model names of the cards. For instructions on how to
assign a name to a line card, refer to “Assigning Names
to the AT-CM Line Cards” on page 181.
App Ver. This column displays the version numbers of the
management software on the AT-CV5M02 Management
Card and the AT-CM Line Cards.If this field is blank for
an AT-CM Line Card, the line card and the management
card have different versions of the management
software. This column does not apply to the AT-CV Line
Cards because they do not have management software.
