Chapter 11: Uploading and Downloading Files
318
5. Enter the necessary information in the fields, defined in Table 40. Be
sure to specify the IP address of the TFTP server in the TFTP Server
IP Address field.
To update a line card, enter in the appropriate field the filename of its
image file stored on the TFTP server. A line card cannot be updated if
its field is blank. You only need to enter image filenames for those line
cards you want to upgrade. For example, to upgrade the AT-S102
Management Software on AT-CM3 Line Cards, you would enter the
appropriate image filename in the AT-CM3xx_AT-3Kxx Image File
Name (ATS102) field. On the other hand, you would leave that field
blank if you were not updating any AT-CM3 Line Cards.
Table 40. TFTP Image Download Configuration Menu
Field Description
TFTP Server IP Address Enter in this field the IP address of the TFTP server that has
the new management software programs for the line cards.
Management Card To update the AT-S99 Management Software on the
AT-CV5M02 Management Card, enter in this field the name
of the new image file that is stored on the TFTP server. Be
sure to include the “.img” extension.
AT-CM3xx_AT-3Kxx Image File
Name (ATS102) To update the AT-S102 Management Software on the
AT-CM301, AT-CM302, and AT-CM3K0S Line Cards, enter
in this field the name of the new image file stored on the
TFTP server. All of the AT-CM3 Line Cards use the same
image file. Be sure to include the “.img” extension.
AT-CM3xx_AM3Kxx Bootloader
Image File Name (ATS102) To update the bootloader file on the AT-CM301, AT-CM302,
and AT-CM3K0S Line Cards, enter in this field the name of
the new bootloader file stored on the TFTP server. All of the
AT-CM3 Line Cards use the same bootloader. Be sure to
include the “.bin” extension.
AT-CM2x2 Image File Name To update the AT-S73 Management Software on the
AT-CM201, AT-CM202, AT-CM202/1, AT-CM202/2,
AT-CM212A/1, and AT-CM212B/1 Line Cards, enter in this
field the name of the new image file stored on the TFTP
server. All of these line cards use the same image file. Be
sure to include the ".img" extension.
AT-CM2Kx Image File Name To update the AT-S73 Management Software on the
AT-CM2K0S Line Card, enter in this field the name of the
new image file stored on the TFTP server. Be sure to include
the ".img" extension.
