Chapter 6: Configuring the Media Converter Line Cards
170
The columns in the table are described in Table 20.
3. Select the port you want to configure. You can configure only one port
at a time. This displays the Port Management Menu shown in
Figure 64.
Figure 64. Port Management Menu
Note
The OAM Configurations selection applies only to Port A on AT-CM
Line Cards. The line card has to be set to an OAM operating mode.
Otherwise, the selection is hidden from view. The AT-CV Line Cards
do not support OAM.
Table 20. Module Configuration Menu
Column Description
Module This field displays the model name of the line card.
Newer versions of the AT-CM2 and AT-CM70S Line
Cards are identified with suffixes like “v2” in their names.
Port This column identifies the port types.
Link This column displays the states of the links between the
ports and the network devices connected to the ports.
The possible states are:
ˆ Online: The port has established a link to a network
device.
ˆ Offline: The port is not connected to a network device
or has not established a link to a device.
Speed This column displays the current speeds of the ports, in
Mbps.
Mode This column displays the current duplex modes of the
ports. The possible duplex modes are:
ˆ Full: Full-duplex mode.
ˆ Half: Half-duplex mode.
Port Management Menu
Module 4 - Port A
Port Configurations
OAM Configurations
Return to Module Configuration Menu...
