Chapter 6: Configuring the Media Converter Line Cards
206
The port statistics for the AT-CM2 and AT-CM70S Line Cards are
described in Table 23.
Web Browser
To display the traffic statistics for the ports on the AT-CM Line Cards from
the web browser windows:
1. Select Module Status & Configuration from the menu bar.
2. In the Chassis View, click one of the ports of the line card whose
statistics you want to view. Or, select the Menu View tab and click the
model name of the line card. You can view the statistics of only one
line card at a time.
3. Select the Port A tab to view the statistics for the fiber optic port or the
Port B tab to view the statistics for the twisted pair port.
4. Click the Port Statistics tab to display the Port Statistics window for
the port you selected. The port statistics for the AT-CM3 Line Cards
are described in Table 22 on page 203. The port statistics for the
AT-CM2 and AT-CM70S Line Cards are described in Table 23 on
page 206.
Table 23. Port Statistics for AT-CM2 and AT-CM70S Line Cards
Row Description
Received
Packets The number of packets received by the port from the
network device connected to it. This statistic is only
available on the AT-CM2K0S Line Card.
Transmitted
Packets The number of packets transmitted by the port. This
statistic is only available on the AT-CM2K0S Line Card.
CRC Errors The number of received packets with CRC errors.
Collisions The number of collisions on the port. This statistic is
applicable only when a port is operating in the half-
duplex mode.
