Converteon Management Software User’s Guide
275
Sending OAM Variable Requests to View MIB Variables
These procedures are used to send OAM variable requests from the fiber
optic ports on Converteon line cards to view the values of MIB objects on
remote devices. For background information, refer to “OAM Variable
Requests” on page 68.
Note
You can use Converteon line cards to send variable requests to
query other OAM-compatible devices for MIB values. However,
since the line cards do not support any of the MIB objects in the
portion of the MIB tree that variable requests can access, they will
not respond to variable requests sent to them by other OAM-
compatible devices.
Menus
To send MIB variable requests from the menus:
1. From the Main Menu, select Module Status and Configuration to
display the Module Status and Configuration Menu shown in Figure 58
on page 158.
2. Select the local AT-CM Line Card you want to send the OAM variable
to its remote OAM counterpart. The Module Configuration Menu is
shown in Figure 63 on page 169.
3. Select Port A, the fiber optic port, on the line card to display the Port
Management Menu shown in Figure 64 on page 170.
4. From the Port Management Menu, select OAM Configurations to
display the OAM Configuration Menu shown in Figure 105 on page
254.
5. From the OAM Configuration Menu, select Send OAM Variable
Request. The prompt in Figure 118 is displayed.
Figure 118. Enter Branch Number Prompt
Converteon
Enter branch number [0 - 255] -
