Chapter 5: Configuring the AT-CV5M02 Management Card

150

Web Browser

To view the operational information from the web browser windows:

1. Select Diagnostics from the menu bar.

2. If the Chassis Information tab is not selected, select it. This window

is for viewing purposes only. The information in the window is
described in Table 17 on page 149.

Running

This field displays the number of hours, minutes, and
seconds since the management card was last powered
on or reset.

Current
Time

This field displays the current date and time.

Flash
PROM

This field displays the status of the Flash PROM on the
management card.

Serial
Interface

This field displays the status of the Console port on the
management card.

RPSA and
RPSB

This field displays the status of the power supplies and
fans, and the temperature and power voltage in the
AT-CV5000 Chassis. A status of “Not present” indicates
an empty power supply slot in the AT-CV5000 Chassis.
Neither the AT-CV1200 Chassis nor the AT-CV1203
Chassis display this information.

Table 17. Chassis Information Menu

Row

Description
