Converteon Management Software User’s Guide
261
8. To view test statistics, select Show Loopback Test Statistics. The
Show Loopback Test Statistics window is shown in Figure 109.
Figure 109. Show Loopback Test Statistics Window
The first line displays the duration of the test in seconds. The counters
display the number of test packets the local OAM client has
transmitted to its remote counterpart over the fiber optic connection,
and the number of packets the local client has received back. The
measurements are given in frames, bytes (octets) and bits. The local
client should receive the same number of test frames, bytes, and bits
as it transmitted. Test frames are sixty octets in length.
9. You can stop the test at any time by selecting Stop Loopback Test
from the OAM Loopback Test Menu.
10. To resume normal network operations on the local and remote line
cards, select Disable Remote Loopback.
11. To clear the statistics counters, select Clear Loopback Test
Statistics.
Show Loopback Test Statistics
Module = 5, Port = 1
Number of Seconds 71
Number of Tx Frames 71
Number of Rx Frames 71
Number of Rx Errored Frames 0
Number of Tx Bytes 4260
Number of Rx Bytes 4260
Number of Rx Errored Bytes 0
Number of Tx Bits 34080
Number of Rx Bits 34080
Number of Rx Errored Bits 0
Return to OAM Loopback Test...
