Chapter 5: Configuring the AT-CV5M02 Management Card

146

Setting the Baud Rate of the Console Port

The following procedures are used to set the baud rate of the Console port
on the management card. The port is used to locally manage the card with
a terminal or a computer with a terminal emulator program. The baud rate
is the only adjustable parameter on the port. Refer to “Starting a Local
Management Session” on page 72
for all of the Console port settings.

Note

Changing the baud rate of the Console port during a local
management session ends your management session. To resume
managing the chassis, change the baud rate of your terminal or
terminal emulator program.

Menus

To set the baud rate of the Console port from the menus:

1. From the Main Menu, select Configuration. The Configuration Menu

is shown in Figure 26 on page 100.

2. From the Configuration Menu, select System Configuration to

display the menu in Figure 27 on page 100.

3. From the System Configuration Menu, select System Parameters

Configuration to display the menu in Figure 28 on page 101.

4. From the System Parameters Configuration Menu, select Terminal

Configuration. The Terminal Configuration Menu is shown in Figure
51.

Figure 51. Terminal Configuration Menu

Terminal Configuration Menu

Data Rate (baud rate) ...

Return to System Configuration Menu...
