Converteon Management Software User’s Guide
285
After you configure an SNMPv3 user, you need to configure SNMPv3
message notification. This configuration is accomplished with the following
tables:
ˆ Configure SNMPv3 Notify Table
ˆ Configure SNMPv3 Target Address Table
ˆ Configure SNMPv3 Target Parameters Table
You start the message notification configuration by defining the type of
message you want to send with the SNMPv3 Notify Table. Then you
define a IP address that is used for notification in the Configure SNMPv3
Target Address Table. This is the IP address of the SNMPv3 host. Finally,
you associate the trap information with a user by configuring the Configure
SNMPv3 Target Parameters Table.
Figure 123 illustrates of how the message notification tables are linked.
Figure 123. SNMPv3 Message Notification Process
SNMPv3 Notify Table
SNMPv3 Target Address Table
SNMPv3 Target Parameter Table
SNMPv3 User Table
SNMPv3 View Table
SNMPv3 Access Table
SNMPv3 SecurityToGroup Table
Linked by View Name
Linked by Group Name
Linked by User Name
or Security Name
Linked by
Security Name
and
Security Model
Linked by Notify Tag
Linked by Target Parameter Name
SNMPv3 Notify Table
