Chapter 6: Configuring the Media Converter Line Cards
188
Setting the Low Power Mode on all the AT-CM3 Line Cards
If you want to set the local power mode on the AT-CM3 Line Cards
individually, perform the previous procedure. If you want to set the mode
on all of the AT-CM3 Line Cards in the chassis, you can save yourself
some time and effort by performing one of these procedures instead.
Note
Activating or deactivating the low power mode does not affect the
network operations of the AT-CM3 Line Cards.
Menus
To set the local power mode on all of the AT-CM3 Line Cards from the
menus:
1. From the Main Menu, select Configuration to display the
Configuration Menu in Figure 26 on page 100.
2. From the Configuration menu, select All CM Line Card
Configurations to display the menu in Figure 76.
Figure 76. All CM Line Card Configurations Menu
3. Select CM301/CM302/CM3K0S LPM to display the menu in
Figure 77.
Figure 77. CM301/CM302/CMCM3K0S LPM Menu
All CM Line Card Configuration Menu
Save all CM Line Card Configuration
Return All CM Line Cards to Default Configuration
CM301/CM302/CM3K0S LPM
Return to Confirmation ...
C301/CM302/CM3K0s LPM Menu
Display Low Power Mode for All CM Line Cards
Set All CM Line Cards to Low Power Mode
Return All CM Line Cards to Normal Mode
Return to All CM Line Card Configuration Menu ...
