Chapter 6: Configuring the Media Converter Line Cards
192
4. To view the default settings of the line card prior to activating them,
select Display Default Configuration. An example of the window is
shown in Figure 80.
Figure 80. Display Default Configuration Window
5. To return the parameter settings on the line card to the default values,
select Return Line Card to Default Configuration from the Line Card
Configuration Menu.
6. At the confirmation prompt, select Yes to return the parameter settings
on the line card to the default values or No to cancel the procedure. If
you select Yes, the parameter settings on the card are returned to the
default settings. The line card will reset if its current operating mode is
different from the default setting. During this process, this message is
displayed on the screen:
Setting operation mode and resetting line card.
7. To save your changes in the master configuration file, wait for the card
to initialize its management software and select Save Line Card
Configuration from the Line Card Configuration Menu.
Display Default Configuration
Slot: 11 Module: AT-CM302
Operational Mode: OAM Visible
Port A(100BaseFX) Port B(100Base-TX)
Port Enable: Enabled Enabled
Negotiation: -- Auto negotiate
Duplex: -- --
Speed -- --
MDI/MDIX: -- --
Flow Control Enable Enable
Ingress Rate Limit: No Limit No Limit
Egress Rate Limit: No Limit No Limit
OAM Configuration
Admin State: Enabled
Mode: Passive
Maximum OAMPDU Size: 1518
Unidirectional Support: Yes
Loopback Support: Yes
Event Support: No
Variable Retrieval Support: Yes
Return to Line Card Configuration...
