Chapter 9: Configuring the Operations, Administration, and Maintenance Client

260

6. From the OAM Loopback Test Menu, select Enable Remote

Loopback.

Caution

The local line card and its remote counterpart stop forwarding
network traffic. Some network traffic may be lost.

Note

There may be a delay of several seconds before the menu reflects
your selection.

If the line card is not configured correctly for the OAM loopback test,
an error message is displayed. The messages are described here.

OAM port is disconnected.

This message indicates that port A on the local line card has not
established a link with its counterpart on the remote line card, possibly
because the fiber optic cable is not connected to the ports.

OAM is not in active mode.

This message indicates that the OAM mode of the line card is set to
the passive mode instead of the active mode. To correct the problem,
perform the procedure “Configuring the OAM Client” on page 254 and
change the Mode setting from Passive to Active in the OAM
Configuration submenu.

Line card not in OAM visible mode.

This message applies only to the AT-CM2 and AT-CM70S Line Cards
and indicates that the line card’s operational mode is set to the OAM
bypass mode instead of the OAM visible mode. To correct the
problem, perform the procedure “Setting the Operating Mode” on
page 176 and sele
ct the OAM visible mode from the Operating Mode
Config Menu.

If you select Enable Remote Loopback and, after several seconds, it
remains deselected, it probably means that support for the loopback
test is disabled on the remote line card.

7. To begin the test, select Start Loopback Test from the OAM

Loopback Test Menu. The test starts immediately.
