Chapter 7: Configuring the Media Converter Line Cards with Remote Peer Management

218

Configuring the Remote Line Cards with the Menus

The menus let you perform these functions on remote line cards:

ˆ

“Displaying the Status of the Remote Line Cards,” next

ˆ

“Naming a Remote Line Card” on page 223

ˆ

“Displaying the Parameter Settings of a Remote Line Card” on
page 223

ˆ

“Configuring Remote Ports” on page 223

ˆ

“Configuring the Low Power Mode on the AT-CM3 Line Cards” on
page 224

ˆ

“Configuring the OAM Clients” on page 224

ˆ

“Changing the Operating Mode” on page 224

ˆ

“Restoring the Default Settings” on page 225

ˆ

“Restoring the Last Saved Configuration” on page 226

ˆ

“Saving the Parameter Settings” on page 227

ˆ

“Resetting the Remote AT-CM3 Line Cards” on page 227

Displaying the

Status of the

Remote Line

Cards

To view the status of the remote line cards from the menus:

1. From the Main Menu, select Remote Module Status and

Configuration to display the Remote Module Status and
Configuration Menu, shown in Figure 91. The menu contains the
status of those remote line cards that have remote peer connections to
their local counterparts in the managed chassis. The columns are
described in Table 26. (AT-CV Line Cards are not included in this
menu because they do not support remote peer management.)

Figure 91. Remote Module Status and Configuration Menu

Remote Module Status and Configuration

Converteon

======================== REMOTE MODULE ======================= ========= FIBER PORT ======== ======== COPPER PORT =======

Mod_Name CardTypeVer

VER

OperMode

FrmSz

LPM

Slot CPM

ST

SP

FC

IngRL

EgrRL

OAM

ST

SP

FC

IngRL EgrRL AN

1

-----------

------- -------

-----

---

---- ---

--

---

--

-----

-----

---

--

--- --

----- ----- --

2 Reg11_r

AT-CM3K0S

V400

OAM_LT

10240

ON

1

Y

*

1G

Y

0

0

oo*

*

1G

Y

0

0

Y

3 Reg20_r

AT-CM301

V400

OAM_LT

10240

ON

1

Y

*

100

Y

0

0

oo*

*

100 Y

0

0

Y

4 Reg21_r

AT-CM301

V400

OAM_LT

10240

ON

1

Y

*

100

Y

0

0

oo*

*

100 Y

0

0

Y

5 Area2a_r

AT-CM301

V400

OAM_LT

10240

ON

1

Y

*

100

Y

0

0

oo*

*

100 Y

0

0

Y

6 --------

-----------

------- -------

-----

---

--

---

--

---

--

-----

-----

---

--

--- --

----- ----- --

7 --------

-----------

------- -------

-----

---

--

---

--

---

--

-----

-----

---

--

--- --

----- ----- --
