Converteon Management Software User’s Guide
129
4. To clear all the messages from the log, select Clear Event Log from
the Event Log Menu.
Web Browser
To view the event log from the web browser windows:
1. Select Administration from the menu bar.
2. If the Event Log tab isn’t selected, select it. The Event Log tab, shown
in Figure 42, displays the messages from oldest to newest. Refer to
Table 12 on page 123 for the descriptions of the columns and Table 13
on page 124 for the event messages and their meanings.
Figure 40. Event Log Tab
3. To clear all of the messages in the log, click the Clear Event Log
button at the bottom of the tab.
Remote SFP Tx Power
High|Low Alarm in linecard
n Report The laser output of a remote SFP module
either exceeded the operating range
(High) or dropped below the range (Low).
Clear The laser output of a remote SFP module
returned to the operating range.
Remote SFP Rx Power
High|Low Alarm in linecard
n Report The laser input of a remote SFP module
either exceeded the operating range
(High) or dropped below the range (Low).
Clear The laser input of a remote SFP module
returned to the operating range.
Table 14. SFP Module Event Messages
Message Classification Definition
