Converteon Management Software User’s Guide
295
Subtree Mask A subtree mask in hexadecimal format. This is an optional
parameter used to further refine the value in the View Subtree
parameter. This parameter is in binary format.
The relationship between a subtree mask and a subtree is
similar to the relationship between an IP address and a subnet
mask. The subnet mask further refines the IP address. In the
same way, the OID table entry defines a MIB View and the
subtree mask further restricts a user’s view to a specific the
column and row of the MIB View. The value of the Subnet
Mask parameter is dependent on the subtree you select. For
example, if you configure the View Subtree parameter as MIB,
ifEntry.0.3 has the following value:
1.3.6.1.2.1.2.2.1.0.3
To restrict the user’s view to the third row (all columns) of the
ifEntry MIB, enter the following value for the Subtree Mask
parameter
ff:bf
View Type The possible values are:
I-Included
Enter this value to permit the View Name to see the subtree
specified above.
E-Excluded
Enter this value to not permit the View Name to see the subtree
specified above.
Storage Type The possible values are:
V-Volatile
This selection blocks the management card from saving the
entry in the master configuration file.
N-NonVolatile
This selection allows the management card to save the entry in
the master configuration file when a save command is issued.
Allied Telesis recommends this storage type.
Row Status This parameter appears only when you display the SNMPv3
View Table. The Active value indicates the entry takes effect
immediately.
Table 34. SNMPv3 View Table Parameters
Parameter Description
