13 force crc error register, Table 8-37, Force crc error register – Artesyn ARTM-831X Installation and Use (June 2014) User Manual
Page 138: Base artm fpga
Base ARTM FPGA
ARTM-831X Installation and Use (6806800M76E)
138
8.3.1.13 Force CRC Error Register
4
Drive Signal N54640_INT_
1
MMC: r
RTM: r/w
5
Drive Signal N54640_SPD0
0
MMC: r
RTM: r/w
6
Drive Signal N54640_SUPER_I
0
MMC: r
RTM: r/w
7
Drive Signal N54640_WIRESPD
0
MMC: r
RTM: r/w
Table 8-36 GE Control Register (continued)
Address: 0x0C
Bit Description
Default
Access
Table 8-37 Force CRC Error Register
Address: 0xD
Bit Description
Default
Access
7:0
Force CRC Error.
0x3C: Force configuration CRC Error. CONF_CRC_ERR will be
driven high.
All other values: The Force CRC Error is disabled. Only real CRC
errors will drive CONF_CRC_ERR high.
0
RTM r/w
