L-force | PLC Designer
General Editors

DMS 4.1 EN 03/2011 TD29 811
Scale (Scale start, Scale end, Main Scale, Sub Scale, Frame inside, Frame outside,
Element Frame)
Scale start value limiting the scaling range from below M,BD
Scale end value limiting the scaling range from above M,BD
Main scale distance between two scaling marks indicating coarse scale M,BD
Sub scale distance between two scaling marks indicating fine scale; can be set to 0,
if no subscaling marks shall be displayed M,BD
Frame inside by default this checkbox is activated; deactivating will make the lower
frame line of the circular scaling arc disappear M
Frame outside by default this checkbox is activated; deactivating will make the upper
frame line of the circular scaling arc disappear M
Element Frame by default this checkbox is deactivated; activating will insert a frame
around the bar display
BD
Label (Unit, Font, Scale Format )
LabelPosition chose "OUTSIDE" to locate the scale labels on the outside of the
circular scaling arc, "INSIDE" to locate the scale labels on the
inside of the circular scaling arc M
Unit string that will be displayed below the arrow (M) or below the
midpoint of the range(BD) (per default the string is thought to
indicate the unit used for scaling) M,BD
Font font for unit and scaling range M,BD
Scale Format (C-Syntax) use the C syntax for indicating the formating of the scale
labels; e.g .entering the string "%3.2f s" in this edit field will
cause the scale labels to be displayed with 3 digits,whereof
two digits are located behind the decimal point and followed
by the letter "s" M,BD
max. text width of labels value limiting the maximum width of text labels; usually the
width of the labels will be adjusted automatically. Use this edit
entry in case of failure of the automatic adjustment.
M
text height of labels value defining the height of text labels; usually the height of
the labels will be adjusted automatically. Use this edit entry in
case of failure of the automatic adjustment. M
Bitmap ID variable (only for Image)
Bitmap ID project variable defining the image ID (see image pool) Im
