Lenze PLC Designer PLC Designer (R3-1) - Manual (Page 32)

L-force | PLC Designer
Lenze Specific Functions
30 DMS 4.1 EN 03/2011 TD29

Outputs (VAR_OUT)
Designator / Data type Value / Meaning
Done / BOOL In the "Single measurement" mode: TRUE = Measuring procedure
completed.
In the "Continuous measurement" mode: Without any function
(see input variables from TriggerInput / L_SMC_Trigger_REF
"TouchProbeMode")
Busy / BOOL Block activated, waiting for trigger.
Error / BOOL Error detection: An error has occurred in task assignment or in
communication with the drive.
ErrorID / INT Error number
ValueStored_PosEdge /
BOOL Measured value saved after triggering on positive flank.
RecordedPosition_PosEdge
/ LREAL Measured value in the case of triggering with the positive edge in
SoftMotion units [SM units], i.e. the measured value is supplied to the PLC
application in the same unit in which the axis is also programmed.
ValueStored_NegEdge /
BOOL Measured value saved after triggering on negative edge.
RecordedPosition_NegEdge
/ LREAL Measured value in the case of triggering with the negative edge in
SoftMotion units [SM units], i.e. the measured value is supplied to the PLC
application in the same unit in which the axis is programmed.
ActivationLevel / BOOL Level of the TP input at the time of TP function activation in the drive. The
application can detect the nature of the first active edge by evaluating the
activation level when a "positive or negative edge" is assigned.
CommandAborted / BOOL Block aborted by means of L_SMCAbortTrigger. The outputs "Busy" and
"Done" are reset.
