L-force | PLC Designer
Menu Commands sorted by Categories
466
DMS 4.1 EN 03/2011 TD29
Text: In the edit window enter any text which should be displayed in the currently
selected cell. Use
will be replaced by the actual values when the page is printed. Button
opens the list
of available placeholders:
Placeholders for common information:
{Page}
Running page number, for example "3"
{Pages}
Total number of pages, for example "23"
{Date}
Current date dd-mm-yyyy, for example "07.07.2006"
{Time}
Current time hh-mm, for example "17:55"
Placeholders for information as defined in the Project Information:
{Path}
Location of the project file, for example "D:\projects"
{File}
Name of the project file, for example "mach1.project"
{Chapter}
Chapter number + Chapter name: The chapter number results from the position
of the object in the "Documentation tree" as defined via the Document Project
dialog. Header level "1" is used for objects which in the POUs or Devices tree are
directly positioned below the root. Objects indented below get header levels 2
and higher. Example: "3.1 POU PLC_PRG.action1" PLC_PRG is the third object
from the POUs view to be documented, action1 is assigned to PLC_PRG.
{Size}
Size of the project file, for example "65,42 KB (66.989 bytes)"
{MS-DOS Name}
MS-DOS name of the project file, for example "D:\COD~1.0PR\UN2A48~1.PRO"
{Created}
Creation date of project file, for example "07.07.2006 17:36"
{Changed}
Date of last modification of project file, for example "07.07.2006 17:36"
{Last Access}
Date of last access of project file, for example "07.07.2006 17:36"
{Attributes}
File attributes: R=read only / H= Hidden / A=Archive / S=System
{Profile}
Name of the currently used profile, for example "»PLC Designer« V3.x"
{Company}
Company name
{Title}
Project title
{Version}
Project version number
{Default Namespace}
Default namespace, relevant if project is used as library
{Author}
Author name
{Description}
Description
Picture: Use button
to get the standard dialog for browsing for a file. Select the
desired image file to get it inserted in the currently selected cell.
