12.35.3 Default Navigators
View commands - Default Navigators
The 'Default Navigators' plug-in provides the following commands for command
category 'View' which will be visible as windows in the user interface:
• POUs
• Devices
By default each view in the upper right corner has a button for opening a menu
with the following commands and options:
Open in editor: Opens the object in the appropriate editor.
Find object: Dialog 'Find Object' opens, where you can search the objects tree for a
POU name. At Find what: enter the search string (may be a single character) and
activate the desired options:
• Match whole name: The search will provide all object names which exactly match
the sequence of characters of the search string.
• Match case: The search will provide all object names which match the search
string exactly concerning the use of upper and lower letters.
• Match prefix: The search will provide all object names starting with the search
string.
• Match substring: The search will provide all object names containing the search
string.
The found objects will be displayed with Name and Path in the Result window.
Sort by type, Sort by name: The objects get sorted by type or name, and alphabetically.
Sort ascending, Sort descending: The above defined sorting is arranged in ascending or
descending order.
POUs View
Symbol:
In the POUs view window all programming units of the current project (PLC program)
are organized and can be instantiated for the use in an specific application.
Devices View
Symbol:
In the Devices view window all devices needed for the project are configured and the
applications are defined appropriately.
For a description of the toolbar see the main help page on the Default Navigators
commands.
