REPEAT loop
The REPEAT loop is different from the WHILE loop because the break-off condition is
checked only after the loop has been executed. This means that the loop will run
through at least once, regardless of the wording of the break-off condition.
Syntax:
REPEAT
UNTIL
END_REPEAT;
The are carried out until the returns TRUE.
If is produced already at the first TRUE evaluation, then
are executed only once. If never assumes the
value TRUE, then the are repeated endlessly which causes a relative
time delay.
Note: The programmer must make sure that no endless loop is caused. He does this
by changing the condition in the instruction part of the loop, for example by
counting up or down one counter.
Example:
REPEAT
Var1 := Var1*2;
Counter := Counter-1;
UNTIL
Counter=0
END_REPEAT;
Extension to the IEC 61131-3 standard (ExST):
The CONTINUE instruction can be used within a REPEAT loop.
