Extensions to Standard IEC1131-3
Norm-extending Data Types
In addition to the data types according to IEC1131-3 there are also some norm-
extending data types available implicitly in »PLC Designer«:
• UNION
• ANY_TYPE
• LTIME
• WSTRING
• References
• Pointers
union
As an extension to the IEC 61131-3 standard it is possible to declare unions in user-
defined types.
In a union all components have the same offset, that is they all occupy the same
storage location. Thus, assuming a union definition as shown in the following
example, an assignment to name.a also would manipulate name.b.
Example:
TYPE name: UNION
a : LREAL;
b : LINT;
END_UNION
END_TYPE
ANY_TYPE
not yet implemented: As an extension to the IEC 61131-3 standard it is possible to
declare inputs of functions or methods as to be of type ANY_TYPE.
LTIME
As extension to the IEC 61131-3 LTIME is supported as time base for high resolution
timers. LTIME is of size 64 Bit and resolution nanoseconds.
Syntax:
LTIME#
