L-force | PLC Designer
Menu Commands sorted by Categories
440 DMS 4.1 EN 03/2011 TD29

Particular Features
Alternatively, each of the features which are only available with the Professional set,
can be activated (on) or deactivated (off) in particular. For this purpose add or remove a
checkmark in the respective option box. The concerned features belong to the
categories described in the following table. In the last two columns each see the
default setting for the Standard resp. Professional set.
Category Description Standard Professional
Object types:
Data server
Image pool
External file
Recipe manager
Text list
Global network
variable list Only if the checkmark is set for an object type,
that type will appear in the "Add Object " context
menu. Text list and Image Pool objects also will
be created automatically by the visualization if
required. off on
IEC 61131-3
language:
Support extended
programming
features: Only if this feature is activated, the following
object types will appear in the “Add object”
context menu:
- Interface
- Method
- Property
Furthermore, when creating a new POU, the
wizard will offer to extend FBs or implement
interfaces.
The new tabular declaration editor also will offer
to extend FBs, implement interfaces, and
decorate the entire POU or single declarations
with compiler pragmas.
The input assistant will offer declaration
keywords that are used together with object
oriented programming (EXTENDS, IMPLEMENTS,
etc.) off on
