Position (X, Y, Width, Height, ShowCursor, Points)
Note: x/y = 0/0 is in the upper left corner of the editor window. x-axis= horizontal
axis, y-axis=vertical axis.
X
Horizontal position in pixels. 0=left
window border.
R,rR.E.L,F,Bu,
Im
M,BD,Tr
Ta,Te,Sc
Y
Vertical position in pixels. 0=upper
window border.
R,rR.E.L,F,Bu,
Im
M,BD,Tr
Ta,Te,Sc
Width
Width of the element in pixels.
R,rR.E.L,F,Bu,
Im
M,BD,Tr
Ta,Te,Sc
Height
Height of the element in pixels.
R,rR.E.L,F,Bu,
Im
M,BD,Tr
Ta,Te,Sc
ShowCursor
Checkbox to be activated if you want the
value of the traced variables at the
position of the cursor to be displayed.
Tr
Points
[0], X / Y ..... [n], X / Y X/Y-positions (pixels) of the particular
element points. [0] is the starting point
of the element. The subsequent points
are numbered consecutively.
P,pL,C
Center (X, Y)
X
X-position of the turning point (center, ) of the
element
R,rR,E,P,L,pL,C,F,Bu,Im
Y
Y-position of the turning point (center, ) of the
element
R,rR,E,P,L,pL,C,F,Bu,Im
