Lenze Specific Functions

DMS 4.1 EN 03/2011 TD29 43
Inputs/outputs (VAR_IN_OUT)
Designator / Data type Info / Setting options
Axis Reference to the axis. Only one L_SMC_FreeEncoder axis is supported.
FastIO_Out Reference to the EPM S310 I/O compound module.
Inputs (VAR_IN)
Designator / Data type Info / Setting options
xExecute When a new positive edge is set, a new measurement is started. All
outputs of the block are reset to the initial values.
byDigitalOutputSel Selection of the output.
xOutputState Value to which the output is to be written.
lrSwitchPosition Position value at which the output is to be set. Since the position is
transferred in SoftMotion units, the reference transferred is an
AxisRef.
wExternalDelayCompensation The propagation times of the axis positions on the respective fieldbus
are not compensated automatically. This input can be used for setting
the manual compensation for the D0 output. The delay time is
entered in [µs].
Outputs (VAR_OUT)
Designator / Data type Value / Meaning
xDone This output is set to TRUE when the parameter has been written
correctly.
xBusy This output is set to TRUE as long as the writing has not been
completed.
xError This output is set to TRUE if an error occurs during writing. eError
outputs the cause of the error.
ErrorID Error number
