General Editors
676 DMS 4.1 EN 03/2011 TD29

The Attributes entries are done in the Attributes dialog where multiple attributes and
pragmas can be entered in text format. They have to be inserted without enclosing {}
braces, a separate line per each. For the example shown in the following image see the
corresponding textual view above in image "Textual editor view".
Abb. 365 Attributes dialog, example
Each variable is declared in a separate line, the lines are numbered.
You can change the order of lines (line numbers) by selecting a line and move it one up
or down by the Move up resp. Move down command from the toolbar or the
context menu.
The list of declarations can be sorted according to each of the columns by a mouse-
click on the header of the respective column. The column which currently determines
the order, is indicated by an arrow symbol:
(ascending order) or (descending
order). Each further click in the column header changes between ascending and
descending order.
To delete one or several declarations, select the respective lines and use or the
Delete command from the context menu or from the toolbar ( )
