Menu Commands sorted by Categories
424 DMS 4.1 EN 03/2011 TD29

You can activate the following options in order to have some visual assistance during
editing:
Highlight current line: The line where the cursor is placed, is highlighted with the color defined in
the selection list.
Matching brackets: If the cursor is placed before or after a bracket "(" or ")" in a code line, the
corresponding closing resp. opening bracket will be indicated by a rectangle
which is colored as defined in the color selection field. Also, if the cursor is
placed in the first or last line of a bracket scope*, the corresponding line at
the end resp. start of this scope will be indicated also by a rectangle of this
color.
* A bracket scope contains all lines between corresponding keywords (for
example IF and END_IF, see
also tab 'Margin')
End of line markers: The end of each editor line will be marked by a small dash of the defined
color which is placed behind the last position which is occupied by a
character or a white-space.
Wrap guide: If soft or hard word wrap is activated (see above, tab Editing), the defined
wrap margin will be indicated by a vertical line in the defined color.
Caret color: Color of the cursor caret
Selection color: The currently selected area will be highlighted with this color.
Folded line foreground: The header of a closed, folded section of code lines will be written in this
color.
Folded line background: The header of a closed, folded section of code lines will be highlighted in this
color.
Font: Choose the font to be used in the text editor. By a mouse-click on the sample
field you get the standard dialog for setting the font.
Abb. 209 Examples for the settings in the Textarea Dialog
