Menu Commands sorted by Categories

DMS 4.1 EN 03/2011 TD29 301
12.13.16 Insert Negated Contact
Symbol:
This command (category 'FBD / LD / IL') is used to insert a negated contact.
Alternatively a combination of the commands 'Insert Contact' and 'Negation' can be
used to insert a negated contact.
12.13.17 Insert Contact right
Symbol:
Shortcut: +
This command (category 'FBD / LD / IL') inserts a contact in a LD network. The same is
valid as for command Insert Contact, except that the new element will not be inserted
left but right to the current cursor position in line.
12.13.18 Insert Contact Parallel below
Symbol:
Shortcut: +
This command (category 'FBD / LD / IL') inserts a contact parallel to the marked
position in the network. The same is valid as for command Insert Contact Parallel
(above), except that the new contact will be inserted below the selected position.
12.13.19 Insert Negated Contact Parallel below
Symbol:
This command (category 'FBD / LD / IL') is used to insert a negated parallel contact.
Alternatively a combination of the commands 'Insert Contact Parallel (below)' and
'Negation' can be used to insert a negated parallel contact.
