DMS 4.1 EN 03/2011 TD29 805
Static ID, Show frame, Clipping, Transparent, Transparent color Scaletype, Trace
Static ID Identification of the image file to be used for this element (static
definition)
Enter the ID of the image file as used in the respective image pool
(STRING); the name of the pool should be prefixed in order to make
this entry unique (not necessary if the image is managed in the
GlobalImagePool, because this one will be searched first anyway). For
example: "imagepool2.button_image". Im
Show frame If activated: image will be displayed with a frame F,Im
Clipping If the Clip option is selected together with a "Fixed" Scaletype setting
(see below), in case of a frame-element only that part of the
visualization fitting into the frame will be displayed. F,Im
Transparent If activated, the color defined in property 'Transparent color' (see
below) will be displayed transparently Im
Transparent color
Button opens the color selection dialog for selecting a color which
should be displayed transparently if option "Transparent" is activated.
Im
Scaletype Specify here how the image should react on changes of the size of the
elements frame.
ISOTROPC: the image retains its proportions; thus even if height and
width of the frame are modified independently, the heigth-width-ratio
of the image will be kept.
ANISOTROPIC: the image follows the size of the frame, so height and
width of the image can be modified independently.
FIXED: the original size of the image will be maintained regardless of
the size of the frame. Notice if option 'Clipping' is also activated. F,Im
Trace Name of trace source for the visual trace element, The name is
completed by a prefix reflecting the associated path within the device
tree, for example "PLCWinNT.Application.Trace". Tr
