Lenze PLC Designer PLC Designer (R3-1) - Manual (Page 613)

L-force | PLC Designer
General Editors

DMS 4.1 EN 03/2011 TD29 611
Allowed syntax
G0 X Y Z A B C P Q U V W F E H L/O S
G92 X Y Z A B C P Q U V W H L/O
Parameters of the
positioning commands
X Y Z Target position of the Cartesian axes
A B C P Q U V W Target positions of the additional axces
F E Path velocity, acceleration, deceleration
G-Code word identifiers (character address)
H L/O Switch point (H-function)
D Tool radius
S S profile
G-Code word identifiers (character address)
Example
Positioning with line interpolation with defined feed.
G-Code
N0 G92 X10 Y10 (Set the position to 10/10)
N10 G1 X20 F10 (Line interpolation to 20/10 with feed rate 10)
N20 G0 Y20 F100 (Line interpolation to 20/20 with feed rate 100)
Example
Various positioning modes.
G-Code
N0 G92 X100 Y100 F100 (Set the position to 100/100)
N10 G1 X100 Y100 (Make sure the output of this position for one cycle)
N20 G92 X50 Y100 (Set the position to 50/100 by jump)
