12.12.11 Set Active Path
Symbol:
This command (category Device Communication) for which there is also a button in
the Communication Settings dialog, sets the communication channel, currently
selected in the tree below the gateway, as the active path to the controller. This means
that all actions concerning communication will exactly refer to this channel. The
command will also be executed on a doubleclick on the channel entry.
The currently active path will be displayed bold in the list, and "(active)" will be
appended:
If a device has been set as the active path, but was not reachable during the last scan
network, it will be drawn in italics.
Note: The iInformation on which device was recently set as "active path" will be
stored on the local system and can be automatically restored at a Login with not yet
configured communication settings.
12.13 FBD/LD/IL
The command category 'FBD/LD/IL' provides commands for working in the combined
editor for FBD, LD and IL.
12.13.1 FBD/LD/IL Editor commands
The 'Network List Editor' plug-in provides for command category 'FBD/LD/IL' the
following commands for the FBD/LD/IL-Editor, which is a collective editor for the
languages FBD (Function Block Diagram), LD (Ladder Diagram) and IL (Instruction List).
By default these commands are part of the 'FBD/LD/IL' menu. If necessary, open the
Customize dialog, category 'Menu', to view or modify the current menu configuration.
Note: For inserting elements in the FBD and LD editor view regard also the
possibility to drag them directly from the toolbox or from another position within
the editor.
12.13.2 Insert Network
Symbol:
Shortcut: +
This command (category 'FBD / LD / IL') is used to insert a network in the FBD, LD or IL
editor.
