Every interpolation point is visualized with a line. The length of the line is proportional
to the current path velocity. Thus a rough estimation of the velocity behaviour (fast =
long distances and long line, slow = small distances and short line) is possible. If the
interpolator is in acceleration, the line is green. In deceleration the line is red.
Otherwise it is gray.
Depending in the option show preprocessed path the interpolation points are based on
the preprocessed path, when the option is activated, or they are based on the original
path, when not.
12.8.4 Step suppression
Button:
If this CNC option is activated, all lines of the text editor starting wiht "/" will be
ignored. This command is not available in table view.
12.8.5 Show grid
Button:
If this CNC option is activated in menu 'CNC', a visible grid will be added to the graphic
editor. The distance of the grid line depends on the zoom factor configuration. The
grid's size depends on the extent of the path.
12.8.6 Show end points
If this CNC option is activated, all elements will be displayed with end points.
12.8.7 Scroll path view
If this CNC option is activated, the path view scrolls and zooms to the selected
element, whenever a new line is selected in the CNC text editor or table editor. So the
latest selected path element in the text editor is visible in the graphic editor.
