MAPware-7000 Programming Manual 51
1010-1040, Rev. 02
Bit Lamp Displays one of two states depending upon the current
state (On or Off) of the tagged bit or PLC coil. The states
can be a graphic image from the MAPware-7000 graphic
libraries or an imported image.
Word Lamp Displays multiple states depending upon the current state
(On or Off) of the tagged bit or PLC coil. The states can be
a graphic image from the MAPware-7000 graphic libraries
or an imported image.
Bar Graph Displays a bar graph which represents the current value in
a targeted register in internal or PLC memory
Multiple Bar
Graphs Displays up to four bar graphs which represent the current
values in a series of targeted registers in internal or PLC
memory
Analog Meter Displays an analog meter which represents the current
value in a targeted register in internal or PLC memory.
Real Time Trend Displays a line chart that plots the current values of up to 4
targeted registers in internal or PLC memory. The plots are
recorded on either a periodic time interval or triggered.
Historical Trend Same as above except that, instead of displaying real time
information, the data displayed is from reading one of the
data files created in the Data Logger.
Alarm List Displays a list of all alarms that are (or were) activated.
Keypad Displays a numeric keypad
ASCII Keypad Displays a alphanumeric keypad
Custom Keypad Displays a keypad that is customized to your preferences
Clock Objects section Display time and date
Time Displays the time
Date Displays the date
