Maple Systems MAPware-7000 - Manual (Page 311)

MAPware-7000 Programming Manual 311
1010-1040, Rev. 02
17
System timer coil
for 8 sec interval
M00487
Coil
(1 bit) Read
Only PLC7000
Toggle at 50 % duty cycle
18
Timer interrupt
ladder execution
status
M00496
Coil
(1 bit)
Read
Only
PLC7000
ON when Timer Interrupt
program is executing
19
IO1 interrupt
execution status
M00497
Coil
(1 bit) Read
Only PLC7000 ON when I/O Interrupt1
program is executing
20
IO2 interrupt
execution status
M00498
Coil
(1 bit) Read
Only PLC7000 ON when I/O Interrupt2
program is executing
Hold mode
status
M00504
Coil (1 bit) Read
Only PLC7000 ON when PLC is in HOLD
mode
21 ALWAYS ON M00512
Coil
(1 bit) Read
Only PLC7000
This coil is always ON
22 ALWAYS OFF M00513
Coil
(1 bit) Read
Only PLC7000
This coil is always OFF
23
HSC Enable Bit
(CH1)
M00240
Coil
(1 bit) Read/
Write HMC7030A-L
only Start Counting for High
Speed Counter (CH1)
24
HSC Reset
Bit(CH1)
M00241
Coil
(1 bit) Read/
Write HMC7030A-L
only Reset High Speed Counter
(CH1)
25
HSC Enable Bit
(CH2)
M00400
Coil
(1 bit) Read/
Write HMC7030A-L
only Start Counting for High
Speed Counter (CH2)
26
HSC Reset
Bit(CH2)
M00401
Coil
(1 bit) Read/
Write HMC7030A-L
only Reset High Speed Counter
(CH2)
27
HSC Enable Bit
(CH1)-Slot01
M01080
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M Start Counting for High
Speed Counter (CH1) -Slot
01
28
HSC Reset
Bit(CH1)-Slot01
M01081
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M
Reset High Speed Counter
(CH1) -Slot 01
29
HSC Enable Bit
(CH2)-Slot01
M01176
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M Start Counting for High
Speed Counter (CH2) -Slot
01
30
HSC Reset
Bit(CH2)-Slot01
M01177
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M
Reset High Speed Counter
(CH2) -Slot 01
31
HSC Enable Bit
(CH1)-Slot02
M02080
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M Start Counting for High
Speed Counter (CH1) -Slot
02
32
HSC Reset
Bit(CH1)-Slot02
M02081
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M
Reset High Speed Counter
(CH1) -Slot 02
33
HSC Enable Bit
(CH2)-Slot02
M02176
Coil
(1 bit)
Read/
Write
HMC7030A-M,
HMC7035A-M,
HMC7057A-M Start Counting for High
Speed Counter (CH2) -Slot
02
