MAPware-7000 Programming Manual
307
1010-1040, Rev. 02
SW memory (System registers)
Tag
No.
Tag
Name
Tag
Address
Type
Access
Models
Supported
Description
1
Language
SW0001
Register
(2 bytes)
Read/
Write
HMC7000
Writing a value will changes
languages used in wizards
2
Logger Memory
% Usage
SW0002
Register
(2 bytes)
Read
only
HMC7035A-M
HMC7057A-M
Shows percentage use of
logger memory.( 0 to 100)
3
COM3 Status
SW0003_
13
Register
(2 bytes)
Read
only
PLC7008A-ME
only
0 = Communication Error;
1= Communicating with PLC
4
COM1 Status
SW0003_
14
Register
(2 bytes)
Read
only
HMC7000
0 = Communication Error;
1= Communicating with PLC
5
COM2 Status
SW0003_
15
Register
(2 bytes)
Read
only
HMC7057A-M
0 = Communication Error;
1= Communicating with PLC
6
Logger Memory
full Status
SW0003_
00
Register
(2 bytes)
Read
only
HMC7035A-M
HMC7057A-M
1 = Memory full
7
Logger Memory
clear Status
SW0003_
01
Register
(2 bytes)
Read
only
HMC7035A-M
HMC7057A-M
1 = Memory clear routing
being executed
8
RTC Status
SW0003_
02
Register
(2 bytes)
Read
only
HMC7000
RTC fail
9
Historical Alarm
count
SW0004
Register
(2 bytes)
Read
only
HMC7000
Shows no of alarm stored in
history
10
Screen Trigger
Register
SW0005
Register
(2 bytes)
Read/
Write
HMC7000
Shows active screen no. You
can change screen by
writing any valid screen no
in this register
11
Screen saver
time
SW0006
Register
(2 bytes)
Read/
Write
HMC7035A-M
HMC7057A-M
You can change screen time
in run time
12
RTC Day of
Month
SW0010
Register
(2 bytes)
Read
only
HMC7000
RTC day in integer format
(00-31)
13
RTC Month
SW0011
Register
(2 bytes)
Read
only
HMC7000
RTC month in integer
format (01-12)
14
RTC Year
SW0012
Register
(2 bytes)
Read
only
HMC7000
RTC year in integer format
(00-99)
15
RTC Hour
SW0013
Register
(2 bytes)
Read
only
HMC7000
RTC hour in integer format
(00-23)
16
RTC Min
SW0014
Register
(2 bytes)
Read
only
HMC7000
RTC minute in integer
format (00-59)
17
RTC Sec
SW0015
Register
(2 bytes)
Read
only
HMC7000
RTC sec in integer format
(00-59)
18
RTC Day of Week
SW0016
Register
(2 bytes)
Read
only
HMC7000
RTC day of week in integer
format (00-06) with
0=Sunday, …, Saturday=6
