308 MAPware-7000 Programming Manual
1010-1040, Rev. 02
19
Scan time
register
SW0017
Register
(2 bytes)
Read
only
HMC7000
Shows time required to
execute Screen, Screen task
and global task in
millisecond. Use ####.#
format for display
20
COM1 failed
node reconnect
time (Sec)
SW0018
Register
(2 bytes)
Read/
write
HMC7000
Shows time in sec recover
the communication with
failed nodes for port1. The
default value is 60Sec
21
COM2 failed
node reconnect
time (Sec)
SW0019
Register
(2 bytes)
Read/
write HMC7057A-M
Shows time in sec recover
the communication with
failed nodes for port2. The
default value is 60Sec
22
Driver Scan time
register for port1
SW0020
Register
(2 bytes)
Read
only
HMC7000
Shows time required to
execute Screen blocks in
milliseconds. Use ####.#
format for display
23
Driver Scan time
register for port2
SW0021
Register
(2 bytes)
Read
only
HMC7000
Shows time required to
execute Screen blocks in
milliseconds. Use ####.#
format for display
24
COM3 failed
node reconnect
time (Sec)
SW0022
Register
(2 bytes)
Read/
Write PLC7008A-ME
only
Shows time in sec recover
the communication with
failed nodes for port3. The
default value is 60Sec
25
Popup Screen
number
SW0023
Register
(2 bytes)
Read/
Write HMC7035A-M
HMC7057A-M
Value stored in this register
triggers the popup screen
on s20 bit
26 Ladder Scan Time SW046
Register
(2 bytes) Read
only HMC7000
Value is multiple of 0.1
mSec
27
Node Status
Registers for
COM1
SW64-S65
Register
(2 bytes)
Read
only
HMC7000
Shows the status of the
node, whether node is
present or not. Total 2 word
Register are mapped for 32
nodes.
28
Node Status
Registers for
COM1
SW66-S79
Register
(2 bytes)
Read
only
HMC7000
Shows the status of the
node, whether node is
present or not. Total 14
word Register are mapped
for 224 nodes
29
Node Status
Registers for
COM2
SW80-S81
Register
(2 bytes)
Read
only HMC7057A-M
Shows the status of the
node, whether node is
present or not. Total 2 word
Register are mapped for 32
nodes.
