Maple Systems MAPware-7000 - Manual (Page 316)

316 MAPware-7000 Programming Manual
1010-1040, Rev. 02
27 High-speed
counter (HSC)
Current value
(for Channel 2-
Slot 2) MW0207 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Displays the current value
for HSC- Channel 2 Slot 2
28 High-speed
counter (HSC)
Preset value (for
Channel 2- Slot
2) MW0209 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to set the preset value
for HSC- Channel 2 Slot 2
29 High-speed
counter (HSC)
configuration
register (for
Channel 1- Slot
3) MW0300 Register
(2 bytes) Read/
Write HMC7030A-L Use to configure the HSC-
Channel 1 Slot 3
30 High-speed
counter (HSC)
Current value
(for Channel 1-
Slot 3) MW0301 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Displays the current value
for HSC- Channel 1 Slot 3
31 High-speed
counter (HSC)
Preset value (for
Channel 1- Slot
3) MW0303 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to set the preset value
for HSC- Channel 1 Slot 3
32 High-speed
counter (HSC)
configuration
register (for
Channel 2- Slot
3) MW0306 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to configure the HSC-
Channel 2 Slot 3
33 High-speed
counter (HSC)
Current value
(for Channel 2-
Slot 3) MW0307 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Displays the current value
for HSC- Channel 2 Slot 3
34 High-speed
counter (HSC)
Preset value (for
Channel 2- Slot
3) MW0309 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to set the preset value
for HSC- Channel 2 Slot 3
