186 MAPware-7000 Programming Manual
1010-1040, Rev. 02
Resize an Analog Meter object
Move the mouse pointer over one of the resize handles. When the pointer changes to a double-
headed arrow, simply click and drag to a new location.
Trend
The Trend object represents up to four target tag registers on an X/Y plot with values recorded
versus time. Registers can be consecutive or chosen individually. Values plot according to a
predefined time interval or using a time interval as specified by a PLC register. Values can be
read from 8/16/32 bit registers in signed/unsigned, BCD, or floating-point format.
Place a Trend object on screen
1. Use one of the following:
a. click Draw…Display Objects…Real Time Trend from the standard menu
b. click Advanced Objects…Trend from the Draw toolbar
2. Move cursor to a start point for the Trend Graph object. Click and hold mouse cursor.
3. Drag mouse cursor to an end point for the Trend Graph object and release. The object
appears on screen and the Trend Properties box displays.
