MAPware-7000 Programming Manual 297
1010-1040, Rev. 02
Appendix A – Internal Memory Addresses
Each HMC7000 unit has internal memory which can be used for operations that do not require
data from an attached PLC. The number of memory registers available depends upon which
HMC model you have selected. Part of this memory is reserved for specific uses (see Appendix B
– Predefined System Tags) while the rest of the memory is openly available for your application.
Below is a table that defines the internal memory of the HMC7000
Type Name Range Type Access Description
Index Register (I) I00000 0 Register Only
(2 bytes)
Read/Write Index Register
Index Register (J) J00000 0 Register Only
(2 bytes)
Read/Write Index Register
Index Register (K) K00000 0 Register Only
(2 bytes)
Read/Write Index Register
Counter Coils C.0000 0-255
1
Bit Only Read/Write Counter Coils
Counter Registers C0000 0-255 Register Only
(2 bytes)
Read/Write Counter Registers
Timer Coils T.0000 0-255 Bit Only Read/Write Timer Coils
Timer Registers T00000 0-255 Register Only
(2 bytes)
Read/Write Timer Registers
Input Coils X00000 0-31015 Bit Only Read Only Physical Input Coils
Input Registers XW0000 0-3100 Register Only
(2 bytes)
Read Only Physical Input Registers
Note: Input Coils and
Registers share same
memory
Output Coils Y00000 0-31015 Bit Only Read/Write Physical Output Coils
Output Registers YW0000 0-3100 Register Only
(2 bytes)
Read/Write Physical Output Registers
Note: Output Coils and
Registers share same
memory
I/O Configuration
Coils M00000 0-31015 Bit Only Read/Write IO coils for base
expansion modules
