Delete Screen
Deletes the current screen shown in the workspace
Open Screen
A popup dialog box lists all screens, click on one to open
Show Screen
Similar to Open Screen but you can only use this action if
the highlight cursor is on Screens in the Project
Information Window
Nodes
Displays a list of all connections (serial, Ethernet) assigned.
Note: same as clicking on Network Configuration folder in
the Project Information window
Tag Database
Displays the tag list (including predefined tags). Note: same
as clicking on Tags folder in the Project Information
window
Alarm Database
Displays the alarm database. Note: same as clicking on
Alarms folder in the Project Information window
Add Bookmark
Places a bookmark on the screen in the workspace
Clear Bookmark
Removes a bookmark assigned to the screen in the
workspace
Clear All
Bookmarks
Removes all bookmarks from screens
Next Bookmark
Displays the next bookmarked screen (in numerical order)
Previous
Bookmark
Displays the prior bookmarked screen (in numerical order)
Previous
Displays the prior screen on the screen list (in numerical
order)
Next
Displays the next screen on the screen list (in numerical
order)
First
Displays Screen 1
Last
Displays the last configured screen (typically Screen 65004
ASCII Keypad)
Bring to Front
If two or more objects are overlaid on screen, the selected
object is brought to the forefront
