212 MAPware-7000 Programming Manual
1010-1040, Rev. 02
Subtract Tag B from Tag A
Description: Subtract a value residing in the Tag B register to the current value residing in the
Tag A register.
Parameters:

Tag A: this is the destination address

Tag B: this is the source address
Toggle Bit
Description: Toggles (turn off/on) an internal tag or PLC tag coil/bit.
Parameters:

Tag: this is the target address
Turn Bit ON
Description: Set (turn on) an internal tag or PLC tag coil/bit.
Parameters:

Tag: this is the target address

Enable Control: Allows tags to control this task. Note: this option is only available if
configuring a global task or a “while showing” screen task. Only PLC tags are used.
o Enable: if ON, allows task to be executed
o Done: HMC7000 sets this coil after completion of task
o Error: HMC7000 sets this coil if error performing task
Turn Bit OFF
Description: Clear (turn off) an internal tag or PLC tag coil/bit.
Parameters:

Tag: this is the target address

Enable Control: Allows tags to control this task. Note: this option is only available if
configuring a global task or a “while showing” screen task. Only PLC tags are used.
o Enable: if ON, allows task to be executed
o Done: HMC7000 sets this coil after completion of task
o Error: HMC7000 sets this coil if error performing task
USB Data Log Upload
Description: Copies (uploads) a series of data registers into a USB Flash Drive
Parameters:

DateTime: 16-bit register that is used to record the date and time

Group: 16-bit register used to record group data

Start Register For File Name or Filename option:
o File Name:

Status Register:
