MAPware-7000 Programming Manual
25
1010-1040, Rev. 02
Numeric,
ASCII, and
custom
keypads
These are keypads that can be displayed on a screen for
editing purposes.
and
Alarm List
and
Database
Displays preconfigured alarm messages when the tagged bit is
triggered.
Alarm
Buttons
These alarm buttons are used to acknowledge a particular,
next, previous, or all alarms.
Clock
Buttons
Use these objects to display the time and date as read from
the internal RTC (real time clock).
Tags
The tag database is used to assign memorable names to the
PLC and I/O registers that you wish to use. Tags can be
exported and edited.
Logic Blocks
The HMC7000 supports logic blocks that are used to create
relay ladder logic programs.
Data Logger
This feature is used to capture data from PLC or I/O registers
and store this data in retentive memory.
Tasks
The HMC7000 has many preprogrammed ‘tasks’ that make it
even easier to program.
Languages
With the language feature, up to nine different languages can
be used to configure each text object.
This manual is designed as a training manual as well as a reference guide. In this effort, the
manual tries to minimize the amount of time required to become familiar with the HMC7000
product line and how to configure these products using the MAPware-7000 programming
software. Therefore, we strongly recommend that you read each chapter of this manual in the
order that it is presented. To minimize redundancy, concepts explained in a chapter are not
repeated in later chapters.
